DMM-3-BR	Battery Monitor with 200A Shunt Kit for Two Battery Banks	$149.95	View Cart

This little Battery and DC current monitor at an affordable price. Check the House Bank or the twin engine start batteries critical voltages, find charging problems or Phantom power losses. With an extremely low current consumption, so low you can leave it ON all week. Also Check current circulation in the system at glance.



Features:

• Protect your batteries against deep discharge
• Accurate 2 battery banks voltage measurement
• System Charge, Discharge or NET current measurement
• Very low current draw (wont drain batteries)
• Red Backlit Display
• Simple: simply press the right button for functions
• Polycarbonate facing
• Corrosion treated Printed Circuit Board
• Surface Mount Technology with sealed trimers
• Stainless steel hardware for marine environment
• Easy to install and operate (No Programming)
• Two year limited warranty

Specifications:

Voltage measurement range:	8.0 -32.0 volts
Resolution (volts):	0. 1 volts
Measurement precision:	± 0.1 volts (20ºC)
Current measurement range (Limited by available shunts):	0-2000 amps.
Resolution (amperes):	0.1 amps(100A shunt) / 1 amp(500A shunt)
Measurement precision:	0.1 amps. (20ºC)
Operating current requirements (no backlight):	1.0 mA (12.0V) / 2.74 mA (24.0V)
Backlight current requirements:	1.3mA @ 12.0 volts / 1.6mA @ 24.0 volts
Operating temperature range:	0ºC to 40ºC
Storage temperature range:	-30º to+60ºC
Size:	3.52” W. x 1.77” H. x 0.735” D. 8,94 cm x4,49cm x 1,87 cm
